$2,304.00 $1,650.00
Maximum Storage Capacity | |
No of Canisters | 6 |
No of 1/2 cc Straws (10/cane) | 4500 |
Number of 1/2 cc Straws (1 Level Bulk) | 6,200 |
Performance (Hold Time overrides NER specifications) | |
LN2 Capacity w/o Inventory L est | 47.4 |
Static Evaporation Rate L/day | 0.39 |
Working Duration (Full Days) | 76 |
Unit Dimensions | |
Neck Opening in (mm) | 5.0 (127) |
Over Height in (mm) | 26.5 (673) |
Outside Diameter in (mm) | 20.0 (508) |
Canister Height in (mm) | 11.0 (279) |
Canister Diameter in (mm) | 4.0 (102) |
Weight Empty lb. (kg) | 42.0 (19) |
Weight Full liquid lb (kg) | 120.4 (54.6) |
* Static evaporation rate and static holding time are nominal. Actual rate and holding time will be affect by the nature of container use, atmospheric conditions, and manufacturing tolerances.
Chart/MVE Specification Sheet - XC Series
