MVE 1877P-2T-150 - BASIC (FREEZER ONLY, NO PLUMBING/CONTROLLER)
$62,892.00 $52,024.40
MVE 1877P-2T-150 - Basic
Holds 134,400 1/2 cc straws
The MVE Stock Series provides the ultimate in security for the breeding industry and are primarily used to store semen and embryos. The freezers are designed for pull and pack shipment, with a wide neck opening for easy access. Although engineered for full liquid storage, the MVE Stock Series can be operated in vapor using the available vapor storage accessory packs.
Features include:
• Wide neck opening
• Lowest lift over height
• Largest LN2 capacity
-
Maximum Storage Capacity
• High security Straw Capacity (0.5 ml): 347,424
• Number of Canisters (73 mm): 517
• Goblets/Canister : Straws/Goblet: 4 : 168
• Number of SUC-1 Canisters (2.5" x 2.5" x 11"): 539
• Number of 1.2 ml Vials on Canes: 77,616
• Number of 2.0 ml Vials on Canes: 43,120
• Number of 1/2 ss Straws 10/cane: 167,090Performance
• LN2 Capacity w/o Inventory: 1456 liters est.
• LN2 Capacity at Platform Vapor: 250Unit Dimensions
• Neck Opening: 25.0" (635 mm)
• Useable Internal Height: 13.0" (330 mm) per tray
• Inner Diameter: 56.25" (1429 mm) top and bottom tiers
• Overall Height with Auto Fill: 64.6" (1639 mm)
• Door Width Requirement**: 60" (1524 mm)
• Weight Empty: 1721 lbs. (781 kg)
• Weight Full: 4316 lbs. (1958 kg)
Visit https://mvebio.com/cryogenic-freezers/mve-stock-series/ for more information
Basic Model - NO CONTROLLER
TWO Year Parts Warranty • Five Year Vacuum Warranty
Conforms to MDD 93/42/EEC, the Medical Device Directive for the EU. Freezer systems UL/C-UL Listed.
You can purchase the freezer on line and we will bill the shipping separately after purchase or email us your shipping address and we can create an invoice for you.
